Cardiovascular

Introducer (long)

Medical use
Introducers
Basic UDI-DI
5901297INTRODUCERSF7

The INTRODUCER is intended to establish vascular access and enable the percutaneous introduction and exchange of catheters, guidewires, or other interventional devices into the venous and/or arterial vasculature for diagnostic and therapeutic purposes.

Set components:

  • Introducer sheath with valve and drain, with a three-way stopcock
  • Dilator
  • Needle

Intended purpose:

The INTRODUCER is intended to establish vascular access and enable the percutaneous introduction and exchange of catheters, guidewires, or other interventional devices into the venous and/or arterial vasculature for diagnostic and therapeutic purposes

    Available versions



    Reference: Sheath
    size
    [F]    		 Sheath
    length
    [mm]    		 Colour
    identification    		 Dilator
    size
    [F]    		 Angiographic needle
    size
    [G]
    INT5F50 5 500 grey 5 18
    INT5F55 5 550 grey 5 18
    INT5F60 5 600 grey 5 18
    INT5F65 5 650 grey 5 18
    INT5F70 5 700 grey 5 18
    INT5F80 5 800 grey 5 18
    INT5F90 5 900 grey 5 18
    INT6F50 6 500 green 6 18
    INT6F55 6 550 green 6 18
    INT6F60 6 600 green 6 18
    INT6F65 6 650 green 6 18
    INT6F70 6 700 green 6 18
    INT6F80 6 800 green 6 18
    INT6F90 6 900 green 6 18
    INT7F50 7 500 orange 7 18
    INT7F55 7 550 orange 7 18
    INT7F60 7 600 orange 7 18
    INT7F65 7 650 orange 7 18
    INT7F70 7 700 orange 7 18
    INT7F80 7 800 orange 7 18
    INT7F90 7 900 orange 7 18
    INT8F50 8 500 blue 8 18
    INT8F55 8 550 blue 8 18
    INT8F60 8 600 blue 8 18
    INT8F65 8 650 blue 8 18
    INT8F70 8 700 blue 8 18
    INT8F80 8 800 blue 8 18
    INT8F90 8 900 blue 8 18
